оƬ×é

Z390

BIOS

AMI UEFI/Legacy BIOS

ÄÚ´æ

2xDDR4 2133/2400/2666MHz SO-DIMM£¬up to 64GB

²Ù×÷ϵͳ

Win10,Linux

I/O ½Ó¿Ú

USB

4x USB3.0, 2x USB2.0,1xUSB 2.0 Type A for¼ÓÃܹ·, 1xUSB2.0°åÄÚ²åÕë

COM

COM1: 1xR232£¬COM2: 1xRS485 ´®¿ÚÊý×Ö¸ôÀë

2xRS232°åÄÚ²åÕë

LED

1xHDD LED

À©Õ¹

PCIe/M.2/Mini-PCIe

1x Mini-PCIe ¿ÉÖ§³Ö4G/5G(´øSIM¿¨²Û£©

2x PCIex4

ÏÔʾ

Graphics Processor

Intel? UHD Graphics

Interface

HDMI+DVI-D,£¨DVI-DÓëVGA ColayÉè¼Æ£¬¿ÉÑ¡£©

´æ´¢

SATA/M.2/mSATA

1xM.2 2242/2280 SATA/NVMe SSD

1xM.2 2242/2280 SATA SSD

񙮵

Audio IC

Realtek ALC897

Audio Interface

°åÄÚÔ¤Áô²åÕë

ÒÔÌ«Íø

LAN IC

1xi219V, 2x i210AT

 Interface

3xRJ45

µçÔ´

Power Input

12V~24V, DC-in£¬¿íѹ¹©µçÊäÈ룬֧³Ö¹ýѹ£¬¹ýÁ÷ÒÔ¼°·À·´½Ó·À»¤£»

ĬÈÏATģʽ

Power Interface

2Pin·ï»Ë¶Ë×ÓÊäÈë

1x 2PIN remote Ô¶³Ì¿ª¹Ø½ÓÏ߶Ë×Ó

ÆäËü

Watchdog Timer

1 to 255 sec/min

ÎïÀí²ÎÊý

Dimensions

£¨W*H*D)

 260mm*130mm*210mm

Mounting

×ÀÃæʽ

ÊÂÇéÇéÐÎ

Operating Temp.

-20¡æ¡«50¡æ

Storage Temp.

-40~85¡æ

Humidity

0%~90% Humidity, non-condensing

Shock

With SSD: 15G, IEC 60068-2-27, half sine, 11ms duration

Vibration

With SSD:2Grms, IEC 60068-2-64, random£¬5~500Hz£¬1 hr/axis
