H068
»ùÓÚÈðо΢RK3568ƽ̨Éè¼Æ£¬ËĺËCortex-A55¸ß´ï2.0GHz´¦Öóͷ£Æ÷£¬´îÅä4K¸ßÇåÏÔʾÊä³ö£¬ÊÇÀíÏëµÄÊý×Ö±êÅÆ¡¢×ÔÖ÷×°±¸ÒÔ¼°ÐÅÏ¢Ðû²¼ÏµÍ³µÄÓ²¼þ½â¾ö¼Æ»® ¡£
- ?
- »ùÓÚÈðо΢ RK3568 ƽ̨
- ?
- Õû»ú½ÓÄÉÎÞµçÉÈÉè¼Æ
- ?
- Ö§³Ö LPDDR4x 2GB/4GBÄÚ´æ
- ?
- Ö§³Ö eMMC5.1 8GB/16GB/32GB ´æ´¢
- ?
- 1 x HDMI Out 4K@60Hz£¬1 x Mini DP-Out£¬1 x HDMI-IN
- ?
- Ö§³Ö WIFI6 ºÍǧÕ×POEÍøÂç¶Ë¿Ú
- ?
- 1 x USB3.0, 1 x USB2.0, 1 x Type-C
- ?
- 1 x RS232 COM£¬1 x Micro SD
- ?
- Ö§³ÖAndroid 11²Ù×÷ϵͳ
CPU | CPU | RK3568 |
Frequency | 2.0 GHz | |
Processing units | 4 Cores Cortex-A55 | |
Display | Graphic card | ARM Mali-G52 |
Multi displays | Support Dual displays | |
Interface | 1 x HDMI-Out 4K @60Hz, 1 x DP-Out 1920x1080 @60Hz, 1 x HDMI-In 1920x1080 @60Hz | |
Network | Lan IC | 1 x LAN IC YT8521SC |
Lan Interface | 10/100/1000Mbps | |
Lan Connector | 1 x RJ45 | |
Wireless Type | M.2 Key E 2230 Module | |
Wireless Module | AW-XB547NF, WIFI-6/BT5.2 | |
I/O interface | Serial Port | 1 x 9PIN RS232 Connector |
USB | 1 x USB3.0, 1 x USB2.0 1 x Type-C | |
Button | 1 x PowerButton, 1 x Recovery Key | |
SD CARD | 1 x Micro SD Card | |
AUDIO | 1 x Audio Out | |
POWER | 1 x 2.5/5.5 DC-IN Connector | |
System | Memory | LPDDR4x 4GB |
Storage | Onboard EMMC5.1 16GB/32GB | |
OS | Android11 | |
WatchDog | Support | |
Auto Power On | Support | |
RTC Alarm | Auto Power On/Off scheduler, a week as a cycle | |
Power Input | 12v 2.5/5.5 DC-In | |
Dimension | 151(L) x 129(W) x 30(H) mm | |
Operating Temp. | -5~45¡æ | |
Operating Humidity | 10%~90% non-condensing | |
Storage Temp | -20~70¡æ | |
Operating Humidity | 5%~95% non-condensing |
